Fanless Mini PC IPC Intel Celeron J4125 Dual Gigabit Ethernet RS232 HDMI VGA mPICE WiFi 4G LTE 4x USB Support Windows Linux

Fanless Mini PC IPC Intel Celeron J4125 Dual...

Sale price$260.98 Regular price$285.99
Color:
Bundle:

Bundle

SPECIFICATIONS

WiFi: 300Mbps

Video Output: HDMI, VGA

Use: Commercial

USB Ports: 2x USB3.0, 2x USB2.0

Type: MINI PC

Type: Mini Desktop

Support OS: Windows 7, Windows 8, Windows 10, Linux, Ubuntu

Storage: mSATA SSD

RAM: SODIMM DDR3L,DDR4

Processor Model: Intel Celeron J4125

Processor Main Frequency: 2.0GHz

Processor Brand: Intel

Power Adapter: AC100-240V to DC12V-3A

Origin: Mainland China

Network Interfaces: Realtek 8111E Gigabit Ethernet

Model Number: X30G

Memory Capacity: ≥ 4GB

Hard Drive Capacity: 64GB

Graphics Card Type: Integrated Card

Graphics: Intel HD Graphics

Dimension: 136x126x39mm

Construction: Fanless aluminum case cooling

Certification: CE,FCC,RoHS

COM Ports: 2x RS232

Brand Name: XCY

Audio Output: Audio combo jack 3.5mm



Processors

Intel Celeron N2830, 2 cores 2 threads, 2.16GHz, up to 2.41GHz

Intel Celeron 2955U, 2 cores 2 threads, 1.40GHz

Intel Celeron 3205U, 2 cores 2 threads, 1.50GHz

Intel Pentium 3805U, 2 cores 2 threads, 1.90GHz

Intel Celeron J4125, 4 cores 4 threads, 2.0GHz, up to 2.70GHz

Intel Core i3-4005U, 2 cores 4 threads, 1.70GHz

Intel Core i3-5005U, 2 cores 4 threads, 2.00GHz

Memory Types

J4125 models use SODIMM DDR4 RAM 2400MHz

Others CPUs use SODIMM DDR3L RAM 1333/1600MHz

max support to 8GB

Storage

mSATA SSD

Graphics

Intel HD Graphics

Network Interfaces

2x GbE RJ45 Realtek 8111E,supports wake on LAN,PXE

Expansion

1x Mini PCI-E for WiFi/Bluetooth/4G module

OS Support

Windows 7/8.1/10

Windows 10 ioT

Windows 10 Embedded

Linux, Ubuntu

Please Note: J4105 doesn't support windows 7 OS

USB Ports

J4125 : 4x USB3.0, 2x USB 2.0

Other CPUs: 2x USB3.0 2x USB2.0

Wake on LAN

Yes, support

Restore AC power loss

Yes, support

Display Port

1x VGA, 1x HDMI, support dual monitors independently video output

COM Ports

2x RS232

Indicators

1x HDD LED, 1x Power LED

Audio Ports

3.5mm combo audio jack

Construction

Fanless passive cooling

Case

Aluminum Case

Dimension

135x124x40mm

Netweight

0.8Kg

OperatingTemperature

-20℃ to +60℃

RH

5%~90% @30℃,Non-condensing

Power Adapter

Input AC100-240V, Output DC12V-3A

Package List

1x Mini PC X30G

1x AC Adapter

1x Power cord ( EU AU US UK type plug shipped according to buyer’s address )

1x SATA cables

1x User manual


NOTE:
1. Buy No RAM No SSD option, mini PC comes without WiFi and antennas pre-installed;
2. Buy mini PC with RAM and SSD option, mini PC comes with WiFi and antennas pre-installed;
3. Mini PC comes without 3G/4G LTE module pre-installed, please contact us if you need.



  • NOTE:
    1. Buy No RAM No SSD option, mini PC comes without WiFi and antennas pre-installed;
    2. Buy mini PC with RAM and SSD option, mini PC comes with WiFi and antennas pre-installed;
    3. Mini PC comes without 3G/4G LTE module pre-installed, please contact us if you need.
